Free shipping
bersa yapı Black Silent Inner WC Door Lock 40mm Mortise Lock
Lowest price in 7 days
-58%
24.53
AED
58.41
(incl. VAT)
Delivery address
Free shipping
Select your address, find out the delivery date!
International delivery
Trendyol's commitments
Easy and free return in 15 days.
Payment methods
Highlighted features:
bersa yapı Black Silent Inner WC Door Lock 40mm Mortise Lock features
Door Opening Direction
Left
Type
Door Latch
Warranty Period
No warranty
Material
Stainless steel
Origin
TR
Similar items
Shoppers also viewed
10 Pcs Keijo Black 128mm Stainless Handle (12.8 cm between Screw Holes) (Furniture, Cabinet Handle, Handle Model)
bersa yapı Black Silent Inner WC Door Lock 40mm Mortise Lock reviews
12 ratings
4 reviews
Product Q&As
What are the measurements
Answer from BersaStore
Hello, 24 cm height, 7 cm depth, 4 cm from the key location to the outside, it is important to take into consideration the last measurement I mentioned, in order for it to fit the door.
Translated by Google
Hello, we need to buy right opening and left opening separately, right?
Answer from BersaStore
Hello, it is suitable in both directions. There is a screw on the back of the tongue. You can remove the screw and turn the tongue.
Translated by Google
Hello, is the tongue metal or plastic?
Answer from BersaStore
Hello, the tongue part is plastic.
Translated by Google
Can't you bring the 35 mm version of this product?
Answer from BersaStore
Hello, it needs to be in high quantity.
Translated by Google
Product details
Product description
Installation and operation manual -before installing the lock to the door, to adjust it for right or left hand opening door, use a thin screwdriver to pry out the tongue from the tongue turning hole at the back side of the lock.
-put the tongue in the right or left position with the help of your hand.
-mark the place where you will install the lock. The length of the lock case is 180 mm. Drill a hole with an 18 mm drill bit. Measure from the surface of your door and drill the holes for the handle and key at a 20 mm angle in the vertical axis.
-mount your lock with 3.5x25 mm chipboard screw. - mount the lock strike with 3 pieces of 3.5x20 mm chipboard screws.
used mechanically in the building, in the residential doors locking device sliding type: intermediate locking position hand locking production date: 02/2021 required experience and values for classification -the resistance to lateral force on the tongue slider is 2kn.
-to operate the lock with the key without applying lateral force-the largest torque applied to the hub to operate the lock is 10 kn the required largest torque is 1.2 kn.
-the tongue components of the lock and the travel limit stops withstand a torque of 20 nm -the travel resistance of the tongue bolt is a minimum of 12,500 revolutions.
-maximum door mass that the lock can operate is 100 kg-door closing force that the lock can operate is 15 n.
-not designed for fire resistance doors. The protrusion of the lock bolt is min.
10mm
Additional info
- The selling price on Trendyol already includes the export-related costs.
- Sold by .
- Made in Türkiye
- A maximum of 5 units of this product can be ordered. Trendyol reserves the right to cancel orders over 5 units.
- Barcode No: BRS-14102023069-0612
- Origin: TR
