warn VR EVO 12 - 12,000 lbs Winch With Steel Rope and Wireless Remote, 12V

Product description

Ideal for 3/4 and 1-ton pickups and all types of large frame rigs that require longer and heavier pulls.

The VR EVO 12 features IP68-rated waterproof construction, an ultra-reliable Albright® contactor inside a relocatable control pack, and a state-of-the-art, two-in-one remote for added ease of use and versatility.

With it’s fast line-speed and lower amp draw, the VR EVO series of winches are the hardest-working standard-duty winches we’ve ever made, with tactical styling that looks great up front and at a price that won’t pull you out of your budget.

A powerful series-wound motor and planetary gear train deliver faster line speed under load, with lower amp draw IP68-rated waterproof winch construction keeps the elements out High-performance Albright contactor delivers maximum reliability Control packs can be relocated for low-profile installations Durable, one-piece cast-aluminum tie-plate for added strength and durability Two-in-one remote with wired AND wireless options for ease of use and versatility Designed, engineered, and tested by WARN engineers in the U.

S.

A.

Technical Specification: Winch Model: VR EVO 12 Parts Numbers: 103254 (VR EVO 12 Rated Line Pull: 12000 lbs.

(5443 kg) Motor: 12V DC, series wound Electrical Controls: Albright Contactor Remote Control: 2-in-1 plug-in remote with wireless capability and 11.5’ (3.5m) lead Gear Train: 3-stage planetary Gear Ratio: 234:1 Clutch (freespooling): Rotating ring gear clutch Brake: Spring Brake Drum Diameter/ Length: Steel and Synthetic: 2.5”/ 9.0” (6.73cm/ 23cm) Weight: Shipping Steel: 90.81 lbs.

(41.19 kg) Net Product Steel: 73.61 lbs.

(33.39 kg) Rope: Steel: 3/8”x 85’ (9.5mm x 25.9m) Fairlead: Steel: Roller Recommended Battery: 650 CCA min.

for winching Battery Leads: 0.98’’ x 6.5’ (25mm x 2m) Finish: Powder coating over primer undercoating Winch Dimensions: 21” L x 6.3” D x 10.1” H (534mm L x 160.5mm D x 256mm H) Mounting Bolt Pattern: 10.0” x 4.5” (254mm x 114.3mm)
